Performance

600W LED engine
Light Source
20,000 hours
LED Life Expectancy
24,000 lumens
Total Lumen Output of Fixture
2,700K – 6,200K
Variable CTO
Ra≥90
Color Rendering
11°-42°
Zoom Range
150 mm
Diameter of Frontal Lens
22kg (48.5 lbs)
Weight

Overview

Designed for powerful white washes across large areas, the ACME AUTOLUX sets a new standard in performance and control, offering outstanding motion stabilization and creative flexibility.

Equipped with a 600W LED engine, the fixture delivers a brilliant 24,000 lumens through its 150 mm frontal lens. With a wide zoom range from 11° to 42°, it offers seamless transitions from sharp beams and uniform washes. A crisp 6,200K color temperature delivers stunning clarity, while high CRI ensures accurate and vivid color rendering.

For creative flexibility, the AUTOLUX features a color wheel, a frost filter, and a variable CTO for smooth transitions from warm to cool tones. Four individually controllable shutter blades enable precise beam shaping with soft, smooth edge.

Engineered for precise pan and tilt movements, the AUTOLUX guarantees exceptional accuracy in positioning for dynamic performances. What sets the fixture apart is its power cycle position holding function – a standout innovation that allows the fixture to automatically restore the previous settings upon power-up, even without signal control. In addition, a dedicated repositioning button prevents unintentional movement during transport and storage.

With its breakthrough positioning technology and no need for console data recall, the AUTOLUX is the ultimate “set-and-forget” solution—perfect for auto shows, fashion runways, and other roadshows.

Technical Specification

Model

  • Model Name: AUTOLUX
  • Model Code: AUTO 600

Light Source

  • Light Source: 600W LED engine
  • Color Temperature Output of Fixture: 6,200K
  • Life Expectancy: 20,000 hours*
    *Source manufacturer specification

Photometric Data

  • Total Lumen Output of Fixture: 24,000 lumens
  • Color Rendering: Ra≥90

Optical System

  • Zoom Range: 11°-42°
  • Diameter of Frontal Lens: 150 mm

Control

  • 4 touch button control panel
  • Display: LCD display
  • Protocols: DMX512,RDM
  • DMX Protocol Modes: 1
  • Control Channels: 25
  • Firmware Upgrade: Upgrade via DMX link or USB stick

Pan & Tilt

  • Pan Movement: 540°
  • Tilt Movement: 270°
  • Resolution: 16 bit

Colors

  • Linear CTO Color Correction: 2,700K-6,200K
  • 1 Color Wheel: 6, plus open

Frost Filter

  • 1 frost filter

Framing System

  • Shutter Blades: 4 blades, each with separate movement and full blackout
  • Rotation: ±60° of the complete framing system

Other Effects

  • Outstanding strobe effect with variable speed
  • Smooth dimming 0-100% (4 user selectable dimming curves)
  • Power cycle position holding function
  • Free moving mode for outstanding motion stabilization

Electrical and Connectors

  • Input Voltage Range: 100-240Vac; 50/60Hz
  • Power Consumption: 865W
  • Power In/Out: Power connector in/out
  • Data In/Out: 3-pin or 5-pin XLR,RJ45 connector

Physical Information

  • Fixture Dimensions:
    • Width: 376 mm (14.8")
    • Depth: 236 mm (9.3")
    • Height: 592 mm (23.3")
    • Weight: 22 kg (48.5 lbs)

Packing Information

  • Flight Case Dimensions:
    • Width : 940 mm (37")
    • Depth : 580 mm (22.8")
    • Height : 775 mm (30.5")
  • Carton Dimensions:
    • Width : 510 mm (20.1")
    • Depth : 485 mm (19.1")
    • Height : 675 mm (26.6")
    • Weight :
      G.W.: 28 kg (61.7 lbs) (one-pack loader carton)

Work Environment

  • Maximum Ambient Temperature: 45°C
  • Minimum Operating Temperature: -10°C
  • Maximum Surface Temperature: 70°C
  • Protection Rating: IP20

Approvals

  • CE compliant
  • UKCA compliant

Installation

  • Universal working position
  • 2 omega brackets
  • Safety cable attachment point

Included Items

  • Digital user manual
  • Power cable
  • 2 omega brackets (3002000288-B)

Optional Accessories (With Order Code)

  • Flight Case:
    • Standard : Two-pack loader case (63584443)
  • Clamp : C-250B (2060001632-B)
  • Safety Cable: SW-05 (2060001603-E)
  • Signal Cable: 3-pin or 5-pin signal cable
Dimensions
Photometrics
Video
Effects
Colors

Linear CTO Color Correction

2,700K-6,200K
3027002443

Color Wheel: 6 colors, plus open

Red
3027002437
Slot 1

Green
3027002438
Slot 2

Pink
3027002439
Slot 3

Orange
3027002440
Slot 4

Blue
3027002441
Slot 5

Deep Blue
3027002461
Slot 6
Prisms/Frost Filters

1 frost filter

Zoom Range
Framing System

Shutter Blades: 4 blades, each with separate movement and full blackout

Rotation: ±60° of the complete framing system
Download
Show More
Show Less
Optional Accessories

ITEM: AUTOLUX (AUTO 600)

ORDER CODE : 63584443

LOADING Q'TY: Two-pack loader case

CASE WEIGHT: 50 kg (110.2 lbs)

MEAS: 940 x 580 x 775 mm (37'' x 22.8'' x 30.5'')

NAME: SW-05

ORDER CODE : 2060001603-E

MATERIAL: Φ5 Steel wire with plastic bushing

NAME: C-250B

ORDER CODE : 2060001632-B

MAX.load: 250 kg

PACKING: 30pcs/CTN
