Performance

Light Source

5 x 120W RGBWAC+UV LEDs

LED Life Expectancy

20,000 hours

Total Lumen Output of Fixture

8,470 lumens

Variable CTO

2,500K-8,000K

Color Rendering

Ra≥92

Beam Angle

14°-55°

Field Angle

29°-136°

Weight

8.6 kg (19 lbs)

Overview

The ACME LINEFORCE 5 IP is a compact, half-meter linear effect light that packs the same outstanding performance as the LINEFORCE 10 IP in a smaller form. The LINEFORCE series is a game-changing innovation for the lighting market, combining cyclorama light, blinder, bar light, and footlightall all in one.

Equipped with five powerful 120W RGBWAC+UV LEDs, the LINEFORCE 5 IP offers a multi-spectrum output from vivid hues to mysterious UV effects. What sets it apart is ACME’s patented electronic frost system, divided into four linear individually controllable zones. The frost zones enable the user to create multiple combinations, allowing for seamless transitions between different beam angles to create soft looks. With all frost zones activated, you can achieve an ultra-wide wash that covers large areas.

Using the included floor stands, it can rotate from 0-90°, making it a versatile footlight. Whether delivering crisp beams or soft washes, the fixture adapts effortlessly to any creative setup.

Lightweight, highly versatile, and IP66-rated, the LINEFORCE 5 IP is designed to elevate creative lighting designs for any applications—redefining what's possible with a linear light.

Technical Specification

Model

  • Model Name: LINEFORCE 5 IP
  • Model Code: CYC 5 IP

Light Source

  • Light Source: 5 x 120W RGBWAC+UV LEDs
  • Life Expectancy: 20,000 hours*
    *Source manufacturer specification

Photometric Data

  • Light Engine Luminous Output: 10,400 lumens
  • Total Lumen Output of Fixture: 8,470 lumens
  • CCT: 8,000K (+/- 200K)
  • Color Rendering: Ra≥92
  • TM-30 Rf (IES TM-30-15 Fidelity Index): 68
  • TM-30 Rg (IES TM-30-15 Fidelity Index): 128
  • TLCI: 77

Optical System

  • Beam Angle : 14°-55°
  • Field Angle : 29°-136°
  • DMX Controllable Smart Glass technology:
    • Patent No. :
      • CN216010577U
      • US11698183B1
      • DE202023101966U1
      • FR3134870B3

Control

  • 4 touch button control panel
  • Display: OLED display
  • Protocols: DMX512,RDM,Art-Net,sACN
  • DMX Protocol Modes: 4
  • Control Channels: 10/16/19/44
  • Firmware Upgrade: Upgrade via DMX link

Pan & Tilt

  • Tilt Movement: 90° (mounted with floor stands)

Colors

  • Linear CTO Color Correction: 2,500K-8,000K

Other Effects

  • Outstanding strobe effect with variable speed
  • Smooth dimming 0-100% (4 user selectable dimming curves)
  • Tungsten emulation
  • Individual pixel control and built-in color macro effects
  • The electronic frost system was divided into four controllable zones, allowing multiple combinations
  • With an ultra-narrow bezel design, it achieves a 90% light-to-screen ratio
  • Uniform wash effect

Electrical and Connectors

  • Input Voltage Range: 100-240Vac; 50/60Hz
  • Power Consumption: 325W
  • Power In/Out: Waterproof power connector in/out
  • Data In/Out: 3-pin or 5-pin waterproof XLR,waterproof RJ45 connector

Physical Information

  • Fixture Dimensions :
    • Without Floor Stands:
      • Width : 500 mm (19.7")
      • Depth : 100 mm (3.9")
      • Height : 162 mm (6.4")
      • Weight : 8.6 kg (19 lbs)

Packing Information

  • Flight Case Dimensions:
    • Width : 1,220 mm (48")
    • Depth : 610 mm (24")
    • Height : 900 mm (35.4")
    • Weight :
      • Standard: G.W.: 189 kg (416.7 lbs) (twelve-pack loader case)
  • Carton Dimensions:
    • Width : 625 mm (24.6")
    • Depth : 335 mm (13.2")
    • Height : 230 mm (9.1")
    • Weight :
      G.W.: 10.5 kg (23.2 lbs) (one-pack loader carton)

Work Environment

  • Maximum Ambient Temperature: 45°C
  • Minimum Operating Temperature: -20°C
  • Maximum Surface Temperature: 70°C
  • Protection Rating: IP66

Approvals

  • CE compliant
  • UKCA compliant
  • cETLus compliant

Installation

  • Horizontal or vertical mounting
  • Universal working position
  • Integrated interlocking system for combining units
  • Vertical Stand: Mounted to one base stand (sold separately). When installed at a tilt, a maximum of 2 fixtures may be connected. When stand vertically, a maximum of 4 fixtures may be connected
  • Horizontal: Utilizing two brackets (supplied) and two clamps (by others), there is no limit to the number of fixtures in the horizontal direction, and a maximum of 6 fixtures may be connected in the vertical direction
  • Vertical: Using one hanging bracket (sold separately) with one clamp (by others), a maximum of 5 fixtures may be connected
  • Floor: Utilizing two brackets (supplied) and two floor stands (supplied)
  • Safety cable attachment point

Included Items

  • Digital user manual
  • Power cable
  • 2 brackets
  • 2 floor stands (63584073)

Optional Accessories (With Order Code)

  • Clamp : C-250B (2060001632-B)
  • Safety Cable: SW-05 (2060001603-E)
  • Signal Cable: 3-pin waterproof signal cable (3017013468) or 5-pin waterproof signal cable (3017013473)
  • Hanging Bracket: 63582969
  • Base Stand: 63582785
  • Glare Shield: 63584114
  • Diffuser Filter (10°): 3005006478
  • Diffuser Filter (40° x 20°): 3005006477
Dimensions
Photometrics
Video
Effects

Beam Angle

Field Angle
Optional Accessories

NAME: SW-05

ORDER CODE : 2060001603-E

MATERIAL: Φ5 Steel wire with plastic bushing

NAME: Waterproof XLR Signal Cable

ORDER CODE : 3017013468(3PIN) / 3017013473(5PIN)

LENGTH: 3m

NAME: C-250B

ORDER CODE : 2060001632-B

MAX.load: 250 kg

PACKING: 30pcs/CTN

NAME: Hanging Bracket

ORDER CODE : 63582969

SIZE: 188 x 123 x 115 mm (7.4'' x 4.8'' x 4.5'')

NAME: Base Stand

ORDER CODE : 63582785

SIZE: 400 x 400 x 55 mm (15.8'' x 15.8'' x 2.2'')

WEIGHT: 15.7 kg (34.6 lbs)

NAME: LINEFORCE 5 IP Glare Shield

ORDER CODE : 63584114
