Model

• Model Name: BLINDER LINE 10 IP
• Model Code: BLB 10 IP

Light Source

• Light Source: 10 x 150W RGBAW LEDs
• Total Lumen Output of Fixture: 26,300 lumens
• Life Expectancy: 20,000 hours*
  *Source manufacturer specification

Optical System

• Beam Angle :
• • W: 23°, 31°, 54°
  • RGBA: 24°, 32°, 54°
• Field Angle :
• • W: 47°, 74°, 130°
  • RGBA: 49°, 79°, 131°
• DMX Controllable Smart Glass technology:
• • Patent No. :
  • • CN216010577U
    • US11698183B1
    • DE202023101966U1
    • FR3134870B3

Control

• 4 touch button control panel
• Display: OLED display
• Protocols: DMX512,RDM,Art-Net,sACN
• DMX Protocol Modes: 2
• Control Channels: 14/55
• Firmware Upgrade: Upgrade via DMX link

Other Effects

• Outstanding strobe effect with variable speed
• Smooth dimming 0-100% (4 user selectable dimming curves)
• Tungsten emulation during dimming
• Individual pixel control and built-in color macro effects

Electrical and Connectors

• Input Voltage Range: 100-240Vac; 50/60Hz
• Power Consumption: 600W
• Power In/Out: Waterproof power connector in/out
• Data In/Out: 3-pin or 5-pin waterproof XLR,RJ45 connector

Physical Information

• Fixture Dimensions:
• • Width: 1,000 mm (39.4")
  • Depth: 103 mm (4.0")
  • Height: 158.5 mm (6.2")
  • Weight: 13.6 kg (30 lbs)

Packing Information

• Flight Case Dimensions 1:
• • Width : 1,220 mm (48.0")
  • Depth : 610 mm (24.0")
  • Height : 530 mm (20.9")
  • Weight :
  • • Standard : G.W.: 107 kg (235.9 lbs) (four-pack loader case)
• Flight Case Dimensions 2:
• • Width : 1,220 mm (48.0")
  • Depth : 610 mm (24.0")
  • Height : 850 mm (33.5")
  • Weight :
  • • Standard : G.W.: 184 kg (405.7 lbs) (eight-pack loader case)
    • North American Standard : G.W.: 209 kg (460.8 lbs) (eight-pack loader case)
• Carton Dimensions:
• • Width : 1,105 mm (43.5")
  • Depth : 285 mm (11.2")
  • Height : 200 mm (7.9")
  • Weight :
    G.W.: 16 kg (35.3 lbs) (one-pack loader carton)

Work Environment

• Maximum Ambient Temperature: 40°C
• Minimum Operating Temperature: -10°C
• Maximum Surface Temperature: 70°C
• Protection Rating: IP66

Approvals

• CE compliant
• UKCA compliant
• cETLus compliant

Installation

• Horizontal or vertical mounting
• Universal working position
• Horizontal: Utilizing two brackets (supplied) and clamps (by others), a maximum of 5 fixtures may be connected
• Vertical: Using one hanging bracket (sold separately) with clamp (by others), a maximum of 3 fixtures may be connected
• Vertical Stand: Mounted to floor stand (sold separately), stand single unit vertically, no other fixtures may be connected
• Floor: Two floor brackets (sold separately) may be attached to base of unit
• Safety cable attachment point

Included Items

• Digital user manual
• Power cable
• 2 omega brackets

Optional Accessories (With Order Code)

• Flight Case 1:
• • Standard : Four-pack loader case (63583274)
• Flight Case 2:
• • Standard : Eight-pack loader case (63583576)
  • North American Standard : Eight-pack loader case (63583041)
• Clamp : C-250B (2060001632-B)
• Safety Cable: SW-05 (2060001603-A)
• Signal Cable: 3-pin waterproof signal cable (3017013468) or 5-pin waterproof signal cable (3017013473)
• Hanging Bracket: 63582969
• Base Stand: 63582785
• Customized Floor Stand w/ Omega Bracket: 63582981 (in pair)
• Customized Floor Stand w/o Omega Bracket: 63583400 (in pair)
